ELECTRIC SYSTEM

MAIN COMPONENT

Motor

48V500W Bafang brand  rear motor

Frame

6061 Alloy Aluminum(optional  stronger rear rack  +USD12 )

with easy release connection

Tyres

26" x 4.00,Kenda mountain tire

Battery

48V16Ah samsung  Li-ion Battery

Rim

Double Alloy Aluminum,

with electric protection circuit,Removable

Fork

MOZO Mechanical aluminum alloy suspention outlock fork

Controller

high efficiency controller

Front & rear Brake

Tektro mechanical Disc-brake (optional Tektro E350 or E500 hydraulic disc brake )

Light

F&R LED light , Spanninga or Wuxing brand

Charger

100~240V, 50-60Hz,

Spokes

front 13G / rear12g Stainless steel

Plug as final market requirement

Derailleur

Shimano tourney 7 speed (optional Alivio 9 or Deore 10 speed )

Displayer

APT  LCD 5-Level display

Handle Bar&stem

Alloy aluminum, promax  (optional adjustable )

PAS

1:1 Pedal Assisted System

fender

optional plastic fender or aluminum alloy with color

PERFORMANCE

Brake Level

tektro Alloy aluminum,power-off when braking (optional Tektro hydraulic brake level)

Speed

30-48Km/h

Chain

Rust resistant chain,KMC

Range

40-80km

Chain wheel

plastic steel 48T*170 mm,Prowheel ( aluminum alloy 38T crank +USD7 )

Max Load

120Kg

Saddle

Soft comfortable Velo  black or Brown color

N.W / G.W

32kg / 40kg

Pedal

Alloy aluminum with reflector,  Wellgo

Carton Size

1600mm*300mm*780mm

Color

matt black, white, red,blue,or optional others

Capacity

75pcs/20ft, 155pcs/40HQ

OEM

acceptable (add your logo on the bike and carton)
