ELECTRIC SYSTEM

MAIN COMPONENT

Motor

48V350W rear drive motor

Frame

6061 Alloy Aluminum

with easy release connection

Tyres

27.5" x  2.3  maxxis tire (optional 27.5*2.1 tire -USD25 )

Battery

48V11Ah samsung  Li-ion Battery

Rim

Double Alloy Aluminum,

with electric protection circuit,Removable

Fork

RST oil aluminum alloy suspention outlock fork

Controller

Sine wave controller, high efficiency,

Front & rear Brake

Tektro mechanical Disc-brake (optional Tektro E350 or E500 hydraulic brake system )

low noise & durable

fender

plastic fender

Charger

100~240V, 50-60Hz,

Spokes

front 13G rear 13G  Stainless steel spokes

Plug as final market requirement

Derailleur

Shimano Acera 7 speed (optional Alivio 9 or Deore 10 speed )

Displayer

CDC6 display

Handle Bar

Alloy aluminum, promax  adjustable

PAS

1:1 Pedal Assistant System

Front & rear light

Spanninga LED light

PERFORMANCE

Brake Level

tektro Alloy aluminum,power-off when braking

Speed

30-48Km/h

Chain

Rust resistant chain,KMC

Range

45-120KM

Chain wheel

aluminum alloy 38T*170 mm

Max Load

120Kg

Saddle

Leather Soft comfortable   velo (black or brown color)

N.W / G.W

28kg /36kg

Pedal

Alloy aluminum with reflector,  Wellgo

Carton Size

1600*250*800mm

Color

matt black, white, red,blue,or optional others

Capacity

77pcs/20ft, 165pcs/40HQ

OEM

acceptable (add your logo on the bike and carton)
