ELECTRIC SYSTEM

MAIN COMPONENT

Motor

48v500W Bafang brand  rear motor

Frame

6061 Alloy Aluminum with rear rack

with easy release connection

Tyres

26" x 4.00,Kenda mountain tire

Battery

48V15Ah samsung  Li-ion Battery

Rim

Alloy Aluminum, Double Wall

with electric protection

circuit, CE ROHS

Fork

Aluminum alloy no suspention front fork

Controller

Sine wave controller, high efficiency

Disc Brake

Tektro mechanical Disc-brake (optional Tektro E350 or E500 hydraulic disc brake )

48v500w

Light

F&R LED light , Spanninga or Wuxing brand

Charger

100~240V, 50-60Hz, CE ROHS UL

Spokes

front 13G rear 12G  Stainless steel

Plug as final market requirement

Derailleur

Shimano tourney 7 speed (optional Alivio 9 or Deore 10 speed )

Displayer

kingmeter SW-LCD display

Handle Bar

Alloy aluminum promax

PAS

1:1 Pedal Assisted System

Grip

leather grip velo

PERFORMANCE

Brake Level

tektro Alloy aluminum,power-off when braking

Speed

28-48Km/h

Chain

Rust resistant chain,KMC

Range

45-80KM

Chain wheel

plastic steel 48T*170 mm,Prowheel ( aluminum alloy 38T crank +USD7 )

Max Load

120Kg

Fender

optional plastic fender or aluminum alloy with color

N.W / G.W

36kg / 42kg

Rear rack

Alloy aluminum

Carton Size

1600*300*780mm

Saddle

Soft comfortable, velo

Capacity

66pcs/20ft, 145pcs/40HQ

Pedal

Alloy aluminum with reflector,  wellgo
